BMW X1 technical data

BMW X1

BMW X1: TECHNICAL DATA

BMW X1BMW X1: TECHNICAL DATA

Here you can find the technical data of the BMW X1.

Read more

TECHNICAL DATA OF THE BMW X1.

Weight
Unladen weight EU in kg
1,475 [1,505]
Max. permissible weight in kg
2,000 [2,025]
Permitted load in kg
600 [595]
Permitted axle load front/rear in kg
990/1,035 [1,020/1,035]
Luggage capacity min. (seats up or roof down) in l
505 [505]
Luggage capacity max. (seats down or roof up) in l
1,550 [1,550]
Trailer load (unbraked) in kg
735 [750]
Trailer load 8% (braked) in kg
-
Trailer load 12% (braked) in kg
1,700 [1,700]
Engine
Cylinders/valves
3/4
Capacity in ccm
1,499
Stroke/bore in mm
94.6/82.0
Engine power in kW (hp) at 1/min
103 (140)/4,600-6,500
Engine torque (Nm) at 1/min
220/1,480-4,200
Compression ratio : 1
11.0
Performance
Top speed in km/h
203 [201]
Acceleration 0–100 km/h in s
9.6 [9.6]
Fuel consumption
Urban in l/100 km
7.6 [7.3]
Extra–urban in l/100 km
5.5 [5.5]
Combined in l/100 km
6.3 [6.2]
CO2 combined emissions in g/km
144 [141]
Electricity consumption, combined in kWh/100km
-
Tank capacity, approx. in l
51
Wheels
Tyre dimensions front
225/55 R17 97 W
Tyre dimensions rear
225/55 R17 97 W
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
-
Growth capacity of lithium–ion battery in kWh
-
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
-
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
-
Electric engine
Electric engine power kW (hp) at 1/min
-
Electric Engine torque (Nm) at 1/min
-
Combined system power
Combined power kW (hp)
-
Combined torque Nm
-
Weight
Unladen weight EU in kg
1,820
Max. permissible weight in kg
2,330
Permitted load in kg
585
Permitted axle load front/rear in kg
1,110/1,270
Luggage capacity min. (seats up or roof down) in l
450
Luggage capacity max. (seats down or roof up) in l
1,470
Trailer load (unbraked) in kg
750
Trailer load 8% (braked) in kg
-
Trailer load 12% (braked) in kg
750
Engine
Cylinders/valves
4/4
Capacity in ccm
1,995
Stroke/bore in mm
90.0/84.0
Engine power in kW (hp) at 1/min
170 (231)/4,400
Engine torque (Nm) at 1/min
450/1,500-3,000
Compression ratio : 1
16.5
Performance
Top speed in km/h
193
Acceleration 0–100 km/h in s
6.9
Fuel consumption
Urban in l/100 km
-
Extra–urban in l/100 km
-
Combined in l/100 km
1.9
CO2 combined emissions in g/km
43
Electricity consumption, combined in kWh/100km
13.8
Tank capacity, approx. in l
51
Wheels
Tyre dimensions front
225/55 R17 97W
Tyre dimensions rear
225/55 R17 97W
Wheel dimensions and material front
7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear
7.5 J x 17 inches, light-alloy
Range and charging
Electric range in km
up to 57
Growth capacity of lithium–ion battery in kWh
34
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
2.4
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
3.2
Electric engine
Electric engine power kW (hp) at 1/min
70 (95)/8,000
Electric Engine torque (Nm) at 1/min
165/100-3,000
Combined system power
Combined power kW (hp)
162 (220)
Combined torque Nm
385

Fuel consumption and CO2 emissions.

  • Disclaimer reference invalid

Fuel consumption and CO2 emissions.

  • The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.

    For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html.

    All technical data are indicative only and varies as per market and configuration. For more information, please check with your local dealer for all fuel consumption and CO2 emissions.
