BMW X1: TECHNICAL DATA.

Select model

Weight

Unladen weight EU in kg 1,480-1,475 [1,510-1,505]
Max. permissible weight in kg 2,000 [2,025]
Permitted load in kg 595-600 [590-595]
Permitted axle load front/rear in kg 990-995/1,035 [1,020/1,035]
Luggage capacity min. (seats up or roof down) in l 505 [505]
Luggage capacity max. (seats down or roof up) in l 1,550 [1,550]
Trailer load (unbraked) in kg 740-735 [750]
Trailer load 8% (braked) in kg 1,400-1,700 [1,400-1,700]
Trailer load 12% (braked) in kg 1,400-1,700 [1,400-1,700]

Engine

Cylinders/valves 3/4
Capacity in ccm 1,499
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 100-103 (136-140)/4,500-6,500
Engine torque (Nm) at 1/min 220/ 1,480-4,200
Compression ratio : 1 11.0

Performance

Top speed in km/h 203 [201]
Acceleration 0-100 km/h in s 9.6 [9.6]
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 7.6 [7.3]
Extra-urban in l/100 km 5.5 [5.5]
Combined in l/100 km 6.3 [6.2]
CO2 combined emissions in g/km 144 [141]
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 51

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1.585
Max. permissible weight in kg 2.065
Permitted load in kg 555
Permitted axle load front/rear in kg 1,090/1,020
Luggage capacity min. (seats up or roof down) in l 505
Luggage capacity max. (seats down or roof up) in l 1,550
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 110 (150)/4,000
Engine torque (Nm) at 1/min 350/1,750-2,750
Compression ratio : 1 16.5

Performance

Top speed in km/h 205
Acceleration 0-100 km/h in s 9.2
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 5.9-5.8
Extra-urban in l/100 km 5.1-5.0
Combined in l/100 km 5.4-5.3
CO2 combined emissions in g/km 141-140
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 51

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

Fuel consumption and CO2 emissions.

  • BMW X1 sDrive18i:
    Fuel consumption in l/100 km (combined): 6.3 [6.2]
    CO2 emissions in g/km (combined): 144 [141]

    The values of the vehicles labeled with (2) are preliminary.

    The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.

    For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html.

    All technical data are indicative only and varies as per market and configuration. For more information, please check with your local dealer for all fuel consumption and CO2 emissions.
