THE BMW X3
TECHNICAL DATA OF THE BMW X3.
| Weight | |
|---|---|
|
Unladen weight EU in kg
|
1,805
|
|
Max. permissible weight in kg
|
2,400
|
|
Permitted load in kg
|
670
|
|
Permitted axle load front/rear in kg
|
1,140/1,390
|
|
Luggage capacity min. (seats up or roof down) in l
|
550
|
|
Luggage capacity max. (seats down or roof up) in l
|
1,600
|
|
Trailer load (unbraked) in kg
|
750
|
|
Trailer load 8% (braked) in kg
|
2,000
|
|
Trailer load 12% (braked) in kg
|
2,000
|
| Engine | |
|---|---|
|
Cylinders/valves
|
4/4
|
|
Capacity in ccm
|
1,998
|
|
Stroke/bore in mm
|
94.6/82.0
|
|
Engine power in kW (hp) at 1/min
|
135 (184)/5,000-6,500
|
|
Engine torque (Nm) at 1/min
|
300/1,350-4,250
|
|
Compression ratio : 1
|
11.0
|
| Performance | |
|---|---|
|
Top speed in km/h
|
215
|
|
Acceleration 0–100 km/h in s
|
8.3
|
| Fuel consumption | |
|---|---|
|
Urban in l/100 km
|
8.4
|
|
Extra–urban in l/100 km
|
6.7
|
|
Combined in l/100 km
|
7.3
|
|
CO2 combined emissions in g/km
|
167
|
|
Tank capacity, approx. in l
|
65
|
| Wheels | |
|---|---|
|
Tyre dimensions front
|
225/60 R18 104W XL
|
|
Tyre dimensions rear
|
225/60 R18 104W XL
|
|
Wheel dimensions and material front
|
7 J x 18 inches, light-alloy
|
|
Wheel dimensions and material rear
|
7 J x 18 inches, light-alloy
|
| Range and charging | |
|---|---|
|
Electric range in km
|
-
|
|
Growth capacity of lithium–ion battery in kWh
|
-
|
|
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
|
-
|
|
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
|
-
|
| Electric engine | |
|---|---|
|
Electric engine power kW (hp) at 1/min
|
-
|
|
Electric Engine torque (Nm) at 1/min
|
-
|
| Combined system power | |
|---|---|
|
Combined power kW (hp)
|
-
|
|
Combined torque Nm
|
-
|
| Weight | |
|---|---|
|
Unladen weight EU in kg
|
1,845
|
|
Max. permissible weight in kg
|
2,420
|
|
Permitted load in kg
|
650
|
|
Permitted axle load front/rear in kg
|
1,155/1,395
|
|
Luggage capacity min. (seats up or roof down) in l
|
550
|
|
Luggage capacity max. (seats down or roof up) in l
|
1,600
|
|
Trailer load (unbraked) in kg
|
750
|
|
Trailer load 8% (braked) in kg
|
2,000
|
|
Trailer load 12% (braked) in kg
|
2,000
|
| Engine | |
|---|---|
|
Cylinders/valves
|
4/4
|
|
Capacity in ccm
|
1,995
|
|
Stroke/bore in mm
|
90.0/84.0
|
|
Engine power in kW (hp) at 1/min
|
140 (190)/4,000 [148 (201)/4,000*]
|
|
Engine torque (Nm) at 1/min
|
400/1,750-2,500 [430/1,750-2,500*]
|
|
Compression ratio : 1
|
16.5
|
| Performance | |
|---|---|
|
Top speed in km/h
|
213
|
|
Acceleration 0–100 km/h in s
|
8.0
|
| Fuel consumption | |
|---|---|
|
Urban in l/100 km
|
6.3-5.7
|
|
Extra–urban in l/100 km
|
5.6-4.8
|
|
Combined in l/100 km
|
5.9-5.1
|
|
CO2 combined emissions in g/km
|
154-136
|
|
Tank capacity, approx. in l
|
60
|
| Wheels | |
|---|---|
|
Tyre dimensions front
|
225/60 R18 104W XL
|
|
Tyre dimensions rear
|
225/60 R18 104W XL
|
|
Wheel dimensions and material front
|
7 J x 18 inches, light-alloy
|
|
Wheel dimensions and material rear
|
7 J x 18 inches, light-alloy
|
| Range and charging | |
|---|---|
|
Electric range in km
|
-
|
|
Growth capacity of lithium–ion battery in kWh
|
-
|
|
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
|
-
|
|
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
|
-
|
| Electric engine | |
|---|---|
|
Electric engine power kW (hp) at 1/min
|
-
|
|
Electric Engine torque (Nm) at 1/min
|
-
|
| Combined system power | |
|---|---|
|
Combined power kW (hp)
|
-
|
|
Combined torque Nm
|
-
|
| Weight | |
|---|---|
|
Unladen weight EU in kg
|
2,065
|
|
Max. permissible weight in kg
|
2,620
|
|
Permitted load in kg
|
630
|
|
Permitted axle load front/rear in kg
|
1,200/1,510
|
|
Luggage capacity min. (seats up or roof down) in l
|
450
|
|
Luggage capacity max. (seats down or roof up) in l
|
1,500
|
|
Trailer load (unbraked) in kg
|
750
|
|
Trailer load 8% (braked) in kg
|
2,000
|
|
Trailer load 12% (braked) in kg
|
2,000
|
| Engine | |
|---|---|
|
Cylinders/valves
|
4/4
|
|
Capacity in ccm
|
1.998
|
|
Stroke/bore in mm
|
90.0/84.0
|
|
Engine power in kW (hp) at 1/min
|
135 (184)/5,000-6,500
|
|
Engine torque (Nm) at 1/min
|
300/1,350-4,000
|
|
Compression ratio : 1
|
11.0
|
| Performance | |
|---|---|
|
Top speed in km/h
|
210
|
|
Acceleration 0–100 km/h in s
|
6.1
|
| Fuel consumption | |
|---|---|
|
Urban in l/100 km
|
-
|
|
Extra–urban in l/100 km
|
-
|
|
Combined in l/100 km
|
2.8
|
|
CO2 combined emissions in g/km
|
64
|
|
Tank capacity, approx. in l
|
50
|
| Wheels | |
|---|---|
|
Tyre dimensions front
|
225/60 R18 104W XL
|
|
Tyre dimensions rear
|
225/60 R18 104W XL
|
|
Wheel dimensions and material front
|
7 J x 18 inches, light-alloy
|
|
Wheel dimensions and material rear
|
7 J x 18 inches, light-alloy
|
| Range and charging | |
|---|---|
|
Electric range in km
|
up to 46
|
|
Growth capacity of lithium–ion battery in kWh
|
34
|
|
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h
|
2.6
|
|
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h
|
3.7
|
| Electric engine | |
|---|---|
|
Electric engine power kW (hp) at 1/min
|
80 (109)/3,140
|
|
Electric Engine torque (Nm) at 1/min
|
265/0-3,170
|
| Combined system power | |
|---|---|
|
Combined power kW (hp)
|
215/292
|
|
Combined torque Nm
|
420
|
